  • View PDF brochure for NetGain HyPer 9HV IS
$6,925.00
Sold Out - Backorder Available

Enter qty and post code to calculate shipping:




The HyPer9 is a Synchronous Reluctance Internal Permanent Magnet (SRIPM) motor delivering outstanding Torque and efficiency, ideal for small to medium vehicle conversions. The HyPer9HV IS kit includes Motor, Controller, low voltage wiring harness, compact display, throttle and main contactor.

Dual shaft option adds an auxiliary shaft to the encoder end of the motor, this Can’t be added later.

Chill plate allows the controller to run at high power levels for longer and is highly recommended for use in warm climates.

User manual

  • Voltage: 144V Nominal
  • DC supply voltage from 90V to 180V
  • Current: 500A
  • Efficiency peak: 95%
  • KW Peak: 100 @ 170v
  • KW continuous 38 @ 3600rpm
  • RPM peak: 8000
  • Torque: 220Nm
  • Regen: Yes
  • Motor dia: 220mm
  • Motor Length:355mm
  • Motor Weight: 55Kg

(mot-H9HVis_)

SKU mot-H9HVis_
Brand NETGAIN
Shipping Weight 70.0000kg
Shipping Width 0.500m
Shipping Height 0.600m
Shipping Length 0.500m
